3 Inch DC plastic impeller Deep Well Solar Water Pump
Product parameters
| Name | S3PC |
| Warranty | 3months-1year |
| Horsepower | 2HP |
| Voltage | Other |
| Application | agriculture |
| MOQ | >1 |
| Delivery time | 15-25 days since you confirmed details |
ADVANCED TECHNOLOGY
- MPPT: Maximum Power Point Tracking
- DSP: Digital Signal Processing - Running Speed Control: stepless speed regulation
- Timing function: Set pump running time
- Over current protection: Motor stops automatically when stucked
- Soft starting protection:Protect the motor & bearing
- Lack of water protection: Restart Automatically upon the Water Level
- Low-voltage / Over-voltage protection: Protect the motor & controller
- Reverse voltage protection: Circuit breaking automatically when reverse connection
- Short-circuit protection: Automatically stops when Short wiring of motor
HOW TO INSTALL A SOLAR PUMP
Solar pumping system mainly consists of PV modules, solar pumping controller / inverter and water pumps, Solar panels convert sunlight to electrical energy which is passed to the solar pump controller, The solar controller stabilizes the voltage and output power to drive the pump motor, Even on cloudy days,it can pump 10% water flow per day. Sensors are also connected to the controller to protect the pump from running dry as well as to automatically stop the pump working when the tank is full.
Solar panel collects sunlight→DC electricity energy → Solar Controller (rectification,stabilization, amplification,filtering)
→available DC electricity→(charge the batteries)→pumping water
Since the sunlight/sunshine is not the same in different countries /regions on earth, the solar panels connection will be slightly changed when installed in different place, In order to ensure the same/similar performance & efficiency,The recommended solar panels power = Pump Power * (1.2-1.5)
FAQ
What do you mean by "head" ?
Head is the maximum vertical height above the pump that the water needs to be pushed and this also includes the losses over the distance that needs to be pumped.
Is there danger in installing a pool pump?
Yes….there is the risk of electrical shock or electrocution.
